FAS Strap
FAS STRAP is an accessory preformed galvanized steel strap with 2 intumescent strips for use as a flute cover when fire-rated walls run parallel to the flutes. It is UL tested and listed and can be used as a component of 1 hr and 2 hr fire-resistant joint systems.
FAS Strap eliminates the need for mineral wool flute fillers and bridging for attachment of the top track to the underside of the deck. The FAS Strap is fabricated from hot-dipped galvanized steel.
- FAS Strap eliminates the need for mineral wool flute fillers and bridging for attachment of the top track to the underside of the deck
- AISI S100, AISI S220
- ASTM E-84, ASTM E-119, ASTM A653, ASTM A924, ASTM A1003, ASTM C645, ASTM E-1966
- UL 263, UL 723, UL 2079 5th Edition, UL ER25033-01
- L-Rating (air leakage) testing for compliance with International Building Code (IBC) and Canadian Building Code (CBC)
- UL listings/approvals include: HW-D-0524; HW-D-0587
- U.S. Patent No.10,214,901
When stored indoors and kept dry in the original package, FAS Strap will provide unlimited shelf life.
Marino\WARE Cold-Formed Steel Framing Products Contain 30% to 37% Recycled Steel
Total Recycled Content: 36.9%
Post-Consumer: 19.8%
Pre-Consumer: 14.4%
