PAPERBACK LATH
Paperback Lath is a diamond mesh lath incorporating both lath and asphalt impregnated paper that is factory bonded to the lath.
Marino\WARE® paperback lath is engineered to meet or exceed industry standards, including ASTM and AISI specifications. We offer consistent quality for reliable performance.
- ASTM C1063
- ASTM C841
- ASTM C847
- ASTM A653
PRODUCT DETAILS
PAPERBACKED DIAMOND MESH LATH
USE: Asphalt paper is factory-bonded to the back. The paper conforms to Federal Specification UU-B-790A, type 1, grade D, style 2.
SIZE: 27” x 97” (686 mm x 2440 mm)
MATERIAL: G-60
PAPERBACKED SELF-FURRING DIAMOND MESH LATH
USE: Uses same mesh configuration as Diamond Mesh Lath but made with 1/4” dimple indentations spaced 1-1/2” o.c. each way. Used as exterior stucco base, column fireproofing, and re-plastering over old surfaces. Available in galvanized only. Paper conforms to Federal Specification UU-B-790A, type 1, grade D, style 2.
SIZE: 27” x 97” (686 mm x 2440 mm)
MATERIAL: G-60
PAPERBACKED V-GROOVE MESH LATH
USE: Same as V-Groove with asphalt paper factory bonded to the back. Paper conforms to Federal Specification UU-B-790A, type 1, grade D, style 2.
SIZE: 27” x 97” (686 mm x 2440 mm)
MATERIAL: G-60
