quickframe®
Designed to streamline rough opening framing, the QuickFrame® metal stud header system offers a pre-cut, high-performance alternative to traditional built-up headers.
The QuickFrame® Rough Opening System is a pre-engineered metal stud box header solution that streamlines installation by reducing the number of components required to frame windows and doors.
The system comes in extra wide flanges and extra-long returns and can be used for exterior or interior framing around any non-load bearing opening.
Simply attach the header and jamb with our easy-to-use QuickFrame Clip for quick installation.
A single QuickFrame member can replace built-up headers and jambs, reducing jobsite labor assembly time by up to 50%.
- ASTM A1003,
- ASTM A653
- ASTM C955
- AISI S240
SEE THE VALUE
PRODUCT DETAILS
Pre-Cut Metal Stud Box Header
The QuickFrame header is a pre-cut metal stud box header that replaces conventional multi-piece assemblies used in curtain wall and window framing. It offers consistent performance and helps reduce jobsite labor by arriving ready-to-install.
- Replaces built-up curtain wall headers
- One header eliminates multiple pieces
- Pre-cut to length
- Reduced assembly time by up to 50%
Pre-Cut Metal Stud Jamb
Designed for non-load bearing framing around openings, the QuickFrame jamb eliminates the need for field-assembled components. It pairs seamlessly with the QuickFrame clip and header to create a complete framing system with fewer materials and faster installation.
- Replaces built-up jamb
- Pre-cut to length
- Equal or greater in strength than traditional multiple piece assemblies
- Up to 50% reduction in assembly time
ONE-PIECE CLIP
The one-piece QuickFrame clip simplifies the connection between header and jamb. With predrilled holes and slotted features, it allows for fast, accurate alignment with minimal effort.
- Simple one-piece clip
- Predrilled holes for easy installation
- Available in 14 gauge with 3” and 3 1/2” flange
- Prefabricated slots to ease adjustments
FAQS
Why Choose the QuickFrame® Rough Opening System?
Framing rough openings with traditional built-up headers and jambs often involves multiple components, added labor, and the risk of inconsistent field assembly. Each piece must be measured, cut, and installed on-site, increasing the chance of delays and errors.
To address these challenges, QuickFrame® offers a pre-cut solution that eliminates unnecessary complexity. Instead of multiple framing components, it uses a single-member system that simplifies installation. As a result, contractors can reduce the number of materials required, speed up framing, and minimize on-site adjustments.
In addition, QuickFrame® is ideal for contractors looking to streamline the installation process and improve jobsite efficiency without compromising strength or performance.
What are some typical QuickFrame applications?
The product is designed for non-load bearing framing around rough openings and performs across a wide variety of construction types. Its pre-cut design and simplified assembly process make it a go-to solution in both commercial and residential projects.
Common applications include:
- Exterior curtain wall headers and jambs
- Interior window and door framing
- Non-load bearing metal stud box header replacements
- Retrofit and tenant improvement projects
- Schools, healthcare facilities, and offices requiring repeatable framing
- Anywhere field-assembled headers are typically used
What is QuickFrame® used for?
QuickFrame® is a pre-cut metal stud box header system used for framing non-load bearing openings around doors and windows. It replaces traditional built-up headers and jambs, reducing jobsite labor and material waste.
Can QuickFrame® be used for both interior and exterior applications?
Yes, QuickFrame® is suitable for both interior and exterior non-load bearing framing applications, including curtain walls, partitions, and retrofit projects.
Does QuickFrame® comply with building codes?
Yes. QuickFrame® is manufactured in accordance with ASTM A1003, ASTM A653, and ASTM C955 standards, and complies with AISI S240 for cold-formed steel framing.
What sizes are available for QuickFrame® components?
Components are pre-cut to custom lengths. The clip is available in 14-gauge steel with 3″ and 3 ½” flanges. For complete sizing details, refer to the technical documentation.
Where can I find QuickFrame® installation guidelines or CAD drawings?
You can find full installation instructions and metal stud header detail files in the Marino\WARE Resource Library.
